1200mm Wide Chrome Towel Rails | 1150mm Pipe Centre| 1150mm Pipe Centre
14 years supplying UK bathrooms, est. February 2012. Free delivery on orders over £200. 5-year manufacturer's warranty on all towel rails.
The 1200mm chrome towel rail is the widest in the standard straight chrome range — a full 1.2 metres of polished chrome with a 1150mm pipe centre, designed for luxury master suites, grand wet rooms, and feature walls in open-plan bathroom spaces. Heights from 600mm to 1000mm deliver up to 2,105 BTU at standard boiler temperatures. At this scale, the rail is as much architectural metalwork as it is a heating appliance — spanning 1200mm of wall with a reflective chrome surface that dramatically amplifies light and perceived space. Central heating, electric, and dual-fuel; 5-year warranty.
Pipe Centre Note: When installing a 1200mm wide chrome towel rail on central heating, your pipework should be set at 1150mm centre-to-centre for straight floor-entry valves. For wall-emerging pipework, use angled or corner valve offsets.
Technical Specifications & Multi-ΔT Heat Output Table
All outputs tested to BS EN 442 standards.
| Height (mm) | Total Bars | Bar Layout | ΔT30 (Heat Pump) | ΔT50 (Standard Boiler) | ΔT60 (High Temp) | Pipe Centres |
|---|---|---|---|---|---|---|
| 600mm | 11 | 3+4+4 | 634 BTU / 186 W | 1,232 BTU / 360 W | 1,562 BTU / 458 W | 1150mm |
| 700mm | 12 | 4+8 | 594 BTU / 174 W | 1,153 BTU / 337 W | 1,462 BTU / 428 W | 1150mm |
| 800mm | 15 | 3+4+8 | 859 BTU / 252 W | 1,668 BTU / 488 W | 2,115 BTU / 620 W | 1150mm |
| 1000mm | 19 | 4+4+4+7 | 1,084 BTU / 318 W | 2,105 BTU / 616 W | 2,669 BTU / 782 W | 1150mm |
Why Choose a 1200mm Width Towel Rail?
A 1200mm width demands serious commitment of wall space and pipework planning. The 1150mm pipe centre is among the widest in the UK market, found only in premium bathroom designs where the plumber has specifically set out for a 1200mm installation. At this scale, the rail can span a double shower cubicle back wall or the main wall of a large freestanding-bath bathroom.
- Ideal Room Suitability: Luxury master bathrooms (18-25 m2), grand wet rooms, open-plan bathroom suites, hotel-specification bathrooms, and any space where the designer intends the towel rail to be the dominant horizontal element.
- Towel Drying Capacity & Ergonomics: The 1200mm bar span accommodates three full bath towels side by side with small air gaps between each — the maximum simultaneous towel capacity in the standard chrome range.
- Installation & Wall Space Considerations: The 1150mm pipe centre is the widest in the range — confirm existing pipework before ordering. Allow approximately 1,300mm total wall clearance. This is a heavy installation when water-filled; structural wall fixings landing in masonry or solid noggins are essential.
Explore Alternative Sizes & Finishes
If 1200mm isn't the exact fit, explore related options:
- Adjacent Widths: Compare with our 1100mm Wide Chrome Towel Rails
- Alternative Finishes in 1200mm Width:
Key Installation & Accessory Compatibility
- Pipe Centre Alignment: Fixed at 1150mm across all heights in this width range.
- Required Valve Hardware: Pair with our Chrome Radiator Valves — straight valves for floor pipework or angled/corner valves for wall pipework.
- Dual Fuel Conversion: Use your rail in summer with a Dual Fuel Kit and Heating Element.
Understanding the ΔT30 / ΔT50 / ΔT60 Output Columns
The three output columns in the table above correspond to different heating system types. ΔT50 is the UK standard (BS EN 442) used by most gas boilers; ΔT30 applies to heat pump systems running at lower flow temperatures; ΔT60 applies to older high-temperature gravity-fed systems. For a full explanation of how these figures work, how to match them to your system, and how to calculate the exact BTU your room needs, see our Towel Rail Heat Output & BTU Calculator Guide.
Frequently Asked Questions
Q: What is the pipe centre for a 1200mm towel rail?
A: The standard pipe centre for a 1200mm wide chrome towel rail is 1150mm, leaving 25mm clearance on each side for valve connections.
Q: Is the 1200mm wide chrome towel rail the widest available in the standard range?
A: Yes — the 1200mm model with a 1150mm pipe centre is the widest in the standard straight chrome ladder range. If you require a wider rail, that would be a bespoke or designer-series product outside this range.
Q: What output does the 1200mm chrome towel rail produce for a very large bathroom?
A: The 1000mm-tall model (19 bars) produces 2,105 BTU / 616W at DT50. For a large master bathroom of 18-22 m2 with average insulation, this is at the lower end of adequacy — a supplementary source such as underfloor heating is recommended for rooms at the upper size range. For heat pump systems, the DT30 output is approximately 1,084 BTU / 318W.
